8.?運輸時總長shipping length

9.?6346(mm)

10.?運輸時總高

11.?Total height during transportation

12.?2800(mm)

13.?運輸寬度

14.?Transport width

15.?2200(mm)

16.?輪胎中心距離Tire center distance

17.?2400(mm)

18.?配重離地間隙

19.?Counterweight ground clearance

20.?1035(mm)

21.?輪胎數量umber of tires

22.?8-825

23.?動臂長度Boom length

24.?3560(mm)

25.?斗桿長度Stick length

26.?1900(mm)

27.?工作范圍

28.?Working Range

29.?舉升高度Maximum lifting height≤

30.?6550(mm)

31.?卸載高度Maximum unloading height≤

32.?5100(mm)

33.?下放深度Maximum lowering depth≤

34.?3380(mm)

35.?舉升范圍Maximum lifting range≤

36.?6590(mm)

37.?推土鏟提升高度≤

38.?Maximum lifting height of earth shovel

39.?300(mm)

40.?推土鏟掘地深度≤

41.?The maximum digging depth of dozer

42.?100(mm)

43.?夾木器抓舉重量

44.?Gripping weight of wood gripper

45.?600-800Kg

46.?夾木器開口寬度

47.?Opening width of wood clamp

48.?1250(mm)

49.?動力系統Dynamical system

50.?發動機型號Model

51.?玉柴

52.?額定功率power

53.??55 KW

54.?冷卻方式Cooling method

55.?水冷

56.?液壓系統Hydraulic System

57.?額定工作壓力Operating Pressure

58.?22mpa

59.?液壓泵Main pump

60.?變量柱塞Variable plunger

61.?液壓閥

62.? Korea

63.?行走馬達

64.?柱塞Plunger

65.?形式Shape

66.?負載敏感系統

67.?Load Sensing System

68.?性能參數performance parameter

69.?鏟斗容量（SAE）Bucket Capacity

70.?0.36m3

71.?爬坡能力Climbing ability

72.?30°

73.?挖掘力Maximum digging force≤

74.?8200N

75.?行走速度Travel speed

76.?35KM/h
